Fluorocarbon coated color steel plate (wood grain)
Category：
Color-coated Sheets
Keywords：
Fluorocarbon coated color steel plate (wood grain)
E-mai：mike@chuangcaigroup.com
WhatsApp：+86-18654318088
- Details
-
PVDF fluorocarbon coatings are the top-of-the-line among existing architectural coatings. As a recognized organic coating with optimal protective properties, it protects metal building panels from damage and maintains its vibrant color for decades. To date, PVDF fluorocarbon coatings have been used in global construction for over 30 years. Today, these buildings still look brand new. PVDF stands for polyvinylidene fluoride. Fluorine atoms have the highest electronegativity and can form very stable carbon-fluorine bonds; its molecules are unique. Therefore, PVDF possesses superior stability, unique resistance to UV photolysis, and exceptional insulation and mechanical properties.
I. Definition of Fluorocarbon Coated Panels:
Fluorocarbon coated panels are colored, baked enamel metal panels created by applying a PVDF fluorocarbon polyester coating to metal panels and baking them at high temperatures.
II. Characteristics of Fluorocarbon Coated Panels:
1. Possesses superior stability, maintaining various performance stabilities even in acidic, alkaline, and heavily polluted environments.
2. Excellent durability; fluorocarbon coated panels can maintain good color and gloss for 20 years outdoors.
3. Excellent processing properties; coated color steel sheets have high toughness and impact resistance and can be processed after embossing.
III. Uses of Fluorocarbon Color-Coated Panels:
IV. Main Indicators of Fluorocarbon Coatings
Fluorocarbon resin content in the coating: ≥70%.
Specific gravity: 1.20±0.1kg/kg
Coating weight: 330㎡/kg (based on 1um dry film)
Solid content 42±2% (weight), 38±2% (volume)
Packaging viscosity: 100~120s
PMT: 249~254℃ (metal peak temperature, referring to the peak temperature of the steel strip surface)
Salt spray test >1000h
MEK: >150 times (MEK wiping)
T-bend 0~1T
Reverse impact >9J
Gloss (60°): 15~40%
Hardness >F
The PVDF coating on the steel sheet is made of polyvinylidene fluoride, a highly durable and weather-resistant material. This coating is highly resistant to ultraviolet radiation, moisture, and other environmental factors, making it suitable for both indoor and outdoor applications.
PVDF fluorocarbon color-coated steel sheets are known for their excellent color retention and vibrant appearance. Even under harsh weather conditions, the PVDF coating ensures that the color remains vibrant and does not fade easily, providing lasting aesthetics and protection.
In addition to aesthetics, PVDF fluorocarbon color-coated steel sheets also have excellent durability. It has strong scratch resistance, wear resistance, and corrosion resistance, ensuring long-term performance and minimizing maintenance needs.
Product Specifications
Coil Thickness 0.085-1.0mm Coating Structure 2/2 Double layer front/Double layer back Coil Width 10-1250mm 2/1 Double coating front and back Coil Inner Diameter Ф508mm/Ф610mm 1/1 Double coating front/Double coating back Coil Outer Diameter 800-1500mm Color Colors can be customized according to customer requirements. Coil Weight 2-10T Thickness Front 15-30 um, Back 5-25 um Color-coated steel sheet color chart
Yes, we are a manufacturer specializing in the production and sale of high quality metal products. Over the years, we have been committed to providing customers with high-quality carbon steel plate/coil, stainless steel plate/coil, PPGI/PPGL, square pile end plate, all kinds of bolts and other metal products.
OEM with competitive price,Full of inventory with large warehouse, Complete sizes,grade and MOQ,24 hours online service, feedback within one hour.More important, we have raw material advantages,and the ppgi coil can be supplied with certification and test.
First our clients can visit factory to see the raw material, production lines, warehouse, transportation and inspection workshop.And you can ask for free sample, we can also process goods as your special requirements. Please do not hesitate to contact us.
If we have the products on stock, delivery time within 15 days. Otherwise, it will take about 25 days for production and delivery.
Please send us the exact details of products inquiry, such as material grade, size(thickness, width, quantity), etc. Then we will quote the best price as you accordingly.
